Meet the WiPT-es
Independent of Cables and Batteries: Pressure and Temperature Combined at a Single Point.
WiPT-es C
WiPT-es-C is a compact autonomous sensor that monitors pressure and temperature wirelessly without batteries in pipelines. Uninterrupted process control via energy harvesting.
Converts the temperature gradient between the process fluid and ambient air into electricity, reducing battery replacement costs to zero.
Lightweight and ruggedized frame that allows easy deployment in tight spaces and complex piping layouts.
Wide pressure measurement ranges coupled with highly accurate temperature tracking.
Fully sealed casing designed to withstand harsh industrial variables, high moisture, and elevated temperatures.
Cable Burden and Battery Maintenance
Routing cables to every valve or pipeline location in industrial plants generates massive extra costs. Battery-operated wireless sensors, on the other hand, turn 'battery tracking and replacement' into an exhausting operational load when thousands of nodes are deployed.
Blind Spots and System Leaks
Failing to track pressure and temperature fluctuations in real time leads to energy losses, structural leaks, and potentially dangerous overpressure situations. In systems lacking data continuity, faults are only discovered after major damage has already occurred.
The WiPT-es Solution
WiPT-es operates utilizing the thermal output of the pipeline itself, thanks to thermoelectric energy harvesting. It completely eliminates battery replacements and secures absolute process control with data refresh rates down to 500ms.
Plug-and-Play with Perpetual Telemetry
Thanks to its compact design, it is easily mounted with customizations tailored for the narrowest spaces. Its maintenance-free architecture allows it to stream pressure and temperature telemetry via the central gateway (Wi-GaTe) for years without manual intervention.
Vacuum and Pressure Combined
Measures not only positive pressure but also negative vacuum values with outstanding precision. This dual-directional telemetry is highly critical for complex pump networks and vacuum loops.
ESCOM Dashboard Integration
All measured parameters can be monitored live on the unified ESCOM Dashboard. By defining critical thresholds, abnormal pressure drops or temperature surges are instantly routed as alarms to the operator.
Operational data like device connectivity states, last telemetry timestamps, and runtime hours are centralized on a single screen. Establish the digital twin of your pipelines with WiPT-es.
Uninterrupted Pipeline Telemetry
Zero out cable and battery costs. Monitor real-time process pressure and temperature data instantly.
Frequently Asked Questions
WiPT-es-C is a wireless & batteryless sensor developed to simultaneously measure pressure (±) and fluid temperature in industrial pipelines. Its compact enclosure enables autonomous monitoring in tight spaces.
The system utilizes advanced Thermoelectric Energy Harvesting technology. It powers the sensor by converting the temperature gradient between the pipe surface heat and ambient air into electrical energy.
WiPT-es-C measures pressure across a wide customizable scale from 0-1 bar up to 0-100 bar. Fluid temperature is monitored with high accuracy between -193°C and +1200°C (depending on the model) via Digital, RTD, or Thermocouple sensor options.
It supports standard BSP and NPT threaded connections. Built on a plug-and-play logic, it can be integrated easily without shutting down process lines. Custom connections can also be manufactured.
All telemetry is tracked with live historical charts. Custom alarm metrics can be designated for sudden pressure drops or overheating. In addition, device uptime and connectivity states are tracked on a single screen.
Yes, its durable IP68-rated enclosure is specifically designed to operate reliably in humid, wet, and corrosive process locations.
WiPT-es-C natively utilizes the wireless BLE (Bluetooth Low Energy) protocol for data transmission.
